Mid-Plane Extraction for Shell Meshing

FEMAP Geometry Midsurface tools like Geometry, Midsurface, Automatic… or Geometry, Midsurface, Offset Tangent Surfaces… can be efficiently used for the sheet solid models which will be meshed using shell elements instead of solid elements.

Please look at the video which shows how it can be done in Femap.
